Schneider Electric – Acti9 iC60H Miniature Circuit Breaker (MCB)
Model: A9F85120 | 1 Pole | 20A | D Curve
Precision Protection. Reliable Performance. Built for Demanding Installations.
The Schneider Electric Acti9 iC60H (A9F85120) is a high-performance 1-pole, 20A Miniature Circuit Breaker (MCB) with a D tripping curve, designed for protecting electrical circuits in residential, commercial, and industrial installations. As part of the world-renowned Acti9 modular device range, this MCB combines superior breaking capacity, compact design, and exceptional reliability — making it a trusted choice for electricians and engineers across the globe.
Key Features
High Breaking Capacity Rated at 10,000A (IEC/EN 60898-1) and 15,000A (IEC/EN 60947-2), the iC60H delivers outstanding short-circuit protection capability — suitable for installations with high prospective fault currents where standard MCBs may fall short.
D Curve — Ideal for High Inrush Applications The D tripping curve is specifically designed for loads that draw high inrush currents at startup, such as motors, transformers, solenoids, and capacitive loads. It trips instantaneously only at currents between 10× to 20× the rated current, preventing nuisance tripping while still providing reliable short-circuit protection.
Compact DIN Rail Design With a slim 1-module (18mm) width per pole and standard 35mm DIN rail mounting, the iC60H integrates seamlessly into any distribution board or electrical panel — maximizing space efficiency without compromising protection.
Acti9 System Compatibility As part of the Acti9 ecosystem, the iC60H is fully compatible with a wide range of Schneider Electric accessories including:
- Auxiliary contacts
- Alarm contacts
- Remote trip units (MX/MN)
- Residual current devices (RCCB/RCBO add-ons)
- iOF+SD dual indication contacts
Safe & Easy Installation Features clearly marked terminal labels, a visible ON/OFF indicator, and top/bottom cable entry — making installation fast, error-free, and compliant with professional installation standards.
Padlockable Handle Equipped with a padlockable toggle mechanism, enabling lockout/tagout (LOTO) procedures for safe maintenance operations.
